Keble Bike Shelter

Rick Mather Architects, Oxford, 2016



Subscribe now to instantly view this image

Subscribe to the Architects’ Journal (AJ) for instant access to the AJ Buildings Library, an online database of nearly 2,000 exemplar buildings in photographs, plans, elevations and details.

Already a subscriber? Sign in



Jim Stephenson (website)     Download Original

  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •

A freestanding bike shelter at Keble College in Oxford

The recently completed bike shelter for Keble College provides shelter for Keble’s 280 on-site bikes. The shelter designed is conceived as a floating translucent cloud curving through five large existing London Plane trees.

The site is sensitive in both historic and landscape terms and is set in the context of William Butterfield’s Grade I-listed ranges; the RMA buildings and Newman Quad. The design of the canopy minimises visual impact on the surrounding trees whilst standing lightly on the ground.

The structure of the canopy carefully steps around the trees above ground and their roots below ground, utilising minimal columns, feet and small pads. The above ground structure is a slim and refined ‘V’ structure of standard galvanized steel posts and off-the-shelf fittings.

The structure supports an overlapping 'scale' of translucent polycarbonate panels that sinuously snake along the existing bike racks and site contours providing shelter and channelling water to the tree roots. The profile of the roof is visible from the garden and provides a consistent variegated horizon to the existing planted slope. The roof is not a complete enclosure with gaps left in the aisles for light and views to the trees.

The design uses standard components, steel sections and regular panel sizes installed in a bespoke manner providing an effective solution for a large shelter on a complex site. The modularisation of elements also allowed the shelter to be installed quickly as a kit of parts.

By night the shelter glows from beneath with a small LED strip illuminating the bikes and the polycarbonate soffit.

Data

  • Begun: Jun 2016
  • Completed: Nov 2016
  • Floor area: 206m2
  • Sector: Transport
  • Total cost: £78,000
  • Procurement: JCT 2011 Minor Works
  • Address: Keble College, Oxford, OX13PG, United Kingdom

Professional Team

Suppliers

  • Polycarbonate roof and cladding: Palram
